Power Factor Correction reduces the amount of input power by up to 30% for full output, making the WFCO WF-6800 Series Deck-Mount Converter Charger an eco-friendly 12-volt system. This innovative unit features industry-first patent-pending Auto-Detect technology, a microprocessor-driven system that intelligently recognizes lithium-ion and lead-acid battery chemistries to automatically adjust the charging profile. Enjoy the convenience of worry-free charging with no manual adjustments required. Multi-stage charging and current monitoring ensure battery life is maximized in both lead-acid and lithium profiles, providing optimized charging for different battery chemistries.

– With Auto-Detect Intelligent Battery Detection
– Selects Correct Charging Profile for Lead-Acid or Lithium-Ion Batteries
– Colors: Two-Tone Gray & Orange
– Case Material: Metal
– Power Input: 1710W
– Input Voltage: 105 VAC – 130 VAC / 60 Hz
– Output Current (LA/LI): 100A
– Power Factor Correction: Unity (0.99)
– Efficiency: 84% (VA Value Under Full Load)
– Converter Type (LA/LI): 3 Stage Converter Charger / 2 Stage Converter Charger
– Voltage Output (LA/LI): 13.2 – 14.4 VDC / 13.6 – 14.6 VDC
– Normal Mode: 13.6 VDC
– Trickle Charge Mode (LA Only): 13.2 VDC
– Bulk Charge Mode: 14.4 VDC / 14.6 VDC
– Outer Dimensions: 9-15/16”W x 3-15/16”H x 13-3/8”D
– Weight: 10.25 lbs.
– Certifications: UL and cUL listed and FCC Class B Compliant
– Safety Features/Protections: Over Current, Over Temperature, Over Voltage, Reverse Polarity
– Specifications are Subject to Change Without Notice or Obligation
– 2-Year Limited Warranty
